Product details of UNI-T UT33D+ Digital NVC Multimeter Voltage Current Resistance Tester Buzzer LCD Backlight

1. A clear LCD display

2. Equipped with comfortable protective cover, test lead hanging slot

3. 2m drop proof with precision protection

4. Auto power off

5. Auto backlight off

6. Loud buzzer

7. Ergonomically designed rotary switch

Specifications Range Accuracy

UT33D+

DC voltage (V) 200.0mV～600V ±(0.5%＋3)

AC voltage (V) 200.0mV～600V

200.0V～600V ±(1.2%+3)

DC current (A) 200.0μA～10.00A ±(1.0%+3)

AC current (A) 200.0μA～10.00A NA

Resistance (Ω) 200.0Ω～200.0MΩ ±(1.0％+2)

200.0Ω～20.00MΩ

Capacitance (F) 2.000nF～2.000mF NA

Features

Max display 1999

Auto power off √

Auto backlight off √

Diode test √

Continuity buzzer √

Drop test 2m

Test probe holder √

Safety rating CAT Ⅱ 600V

Range selection Manual

Battery test

Temperature (°C/°F)

NCV √

General Characteristics

Power AAA battery (zn-mn) 1.5V×2

LCD size 66mm*51mm

Product color Red and grey

Product net weight 473g

Product size 131mm×95mm×58mm

Standard accessories Test lead, manual

Standard individual packing Gift box, manual

Standard quantity per carton 60pcs

Standard carton measurement 640mm×310mm×350m

Specifications Range Accuracy

UT33D+

DC voltage (V) 200.0mV～600V ±(0.5%＋3)

AC voltage (V) 200.0mV～600V

200.0V～600V ±(1.2%+3)

DC current (A) 200.0μA～10.00A ±(1.0%+3)

AC current (A) 200.0μA～10.00A NA

Resistance (Ω) 200.0Ω～200.0MΩ ±(1.0％+2)

200.0Ω～20.00MΩ

Capacitance (F) 2.000nF～2.000mF NA

Standard carton measurement 640mm×310mm×350m

Specifications of the UNI-T UT33D+ Digital NVC Multimeter Voltage Current Resistance Tester Buzzer LCD Backlight

BrandUNI-T

ModelUT33D+

SKU UTDM20

What’s in the box main unit, user manual
